General

Operating Depth
Delrin	200 m
Aluminium Alloy	2000 m
Stainless Steel	2000 m
Titanium	6000 m
Operating Range	6000 m
Frequency Band	15 - 27 kHz
Transducer Beam Pattern	wide-angle, 120 degrees

Connection

Acoustic Connection	up to 9.2 kbit/s
Bit Error Rate	less than 10-¹⁰
Internal Data Buffer	1 MB, configurable
Host Interface [1]	Ethernet or RS-232
Interface Connector	up to 4 connectors, Ethernet and serial combinations

Power

Power Consumption [2]
Stand-by Mode	2.5 mW
Listen Mode	5 - 285 mW
Receive Mode	0.8 W
Transmit Mode	2.8 W, 1000 m range  8 W, 2000 m range  35 W, 3500 m range  65 W, max. available
Power Supply [3]
External	24 VDC (12 VDC)
Internal	Rechargeable battery 5 Ah or 10 Ah

Physical

Housing Options
Delrin	✓
Aluminium Alloy	✓
Stainless Steel	✓
Titanium	✓
Dimensions [4]
Housing	Ø 110x178 mm
Total length	295 mm
Weight dry/wet
Delrin	3850 /1080 g
Aluminium Alloy	4160 /1560 g
Stainless Steel	8000 / 5800 g
Titanium	7780 /5180 g

[1] One RS-232 Interface can be replaced with a RS-422 interface. Contact EvoLogics for more information!
[2] Power consumption for RS-232 interface. Add 500 mW if an Ethernet interface is installed. Add 300 mW if the Wake-Up Module is installed.
      User-configurable Listen Mode is only available with a Wake-Up module installed. Power consumption in Listen Mode depends on Listen Mode settings.
[3] 300 VDC available for 42/65 models. Contact EvoLogics for more information on power supply options!
[4] Dimensions of a Delrin housing, other builds are slightly larger. Dimensions vary depending on housing type and installed options.
      Contact EvoLogics for more information on device dimensions and weights, request a drawing if necessary.
[5] The Wake Up Module is only compatible with RS-232 interface! It is not compatible with Ethernet or RS-422.
      2-interface Wake Up Module version reacts to incoming data on two serial interfaces.
[6] The Power Switch is only compatible with RS-232 interface! It is not compatible with Ethernet or RS-422.
